Opera Consonance Linear200 is all new multi-function tube integrated amplifier, that implements technology from the 20-year-old renowned cyber100series amplifier. It comes with 3 digital and analog inputs and simple but advanced DAC in one box with Ak4490 DAC chip and advanced X-MOS moudul, supporting DSD playback up to DSD256 as well as high resolution PCM formats.
KT120 are auto biased in push-pull regime with cathode negative feedback and hybrid with rectifier design, that ensure steady performance and sound. The Linear200 features 3 digital inputs (USB, Coaxial and Optical).
Specification:
Power Output: 35 watt, RMS 1kHz
Input Sensitivity: 220mV
Noise and Hum: 90dB
Frequency Response : 6Hz-50kHz，-3dB(10 watt)
Input Impedance: 100KΩ
Output Impedance: 4，8Ω
Consumption: 290W
Output interfaces: 1 groups (RCA)
Digital inputs: AUX RCA x 3, Optical x 1(24bit/192k), Coaxial RCA x 1(24bit/192k), USB port x 1(32bit/384K, DSD64(1bit/2.8M)，DSD128 (1bit/5.6M)，DSD256（1bit/11.2M）
Tubes: 12AX7 x 1，12BH7 x 2，5AR4 x 2，KT120x 4
Dimensions: 430 (L) x 380 (W) x 190(H) mm
Weight: 29kg
