Mounted on anti-vibration spikes, the BonaWatt Triton- 250W integrated amplifier offers powerful capabilities, combining the warmth of tube sound with modern, high-efficiency power. The signal conversion between the tube and power sections, based on 16 parallel operational amplifiers, ensures no coloration of the audio signal, allowing the tube section to fully define the tonal character. Triton features two slots on the rear panel for expansion cards developed in collaboration with MuzgAUDIO, the creators of the Reference AUDIO DAC-01S, providing flexibility for integrating multiple functions into a single hybrid system.
- Electron tubes used: 2x 6SL7GT (6N9S) + 2x VR150 + U77.
- Power amplifier circuit: Class D
- Volume control: 128 x 0.5dB = 64dB (±0.15dB) logarithmic resistor ladder, manually paired (±0.05%) military specification resistors, managed by Japanese relays with silver-plated contacts
- Remote control RC-2 (optional), functions: ON / STANDBY, volume control, input selector, mute / unmute, dimmer. Supply voltage: 3 VDC (2x AAA, FR03), dimensions: length (178mm), width (48mm), height (28mm); weight: 280g.
- Outputs: REMOTE
- Inputs: 3 RCA analog inputs.
- Expansion card slots: 2 pcs.
- Available expansion cards: MuzgAUDIO DAC, PHONO preamp, BALANCED input, PRE-OUT.
- Signal-to-noise ratio: 98dB (±1dB)
- Continuous output power @1kHz, 8Ω: 2x 250W RMS (±1%)
- Continuous output power @1kHz, 4Ω: 2x 500W RMS (±1%)
- Peak output power @1kHz, 2.7Ω: 2x 750W RMS (±1%)
- Frequency response @8Wrms, -3dB: 6Hz – 65 kHz (±1%)
- THD+N, @8Wrms, 1kHz: < 1,5% (±0.5%)
- Input sensitivity @8Wrms: 707mVrms
- Power consumption in operation no load / max: 150 W / 1600 W (max)
- Power consumption in sleep mode (“STANDBY”): < 1 W
- Device dimensions: width (450mm), height (300mm), depth (350mm)
- Device weight: 22kg / 25kg (weight in packaging).
- Input impedance: 20kΩ
- Output impedance: 15mΩ
The incredible power allows it to work with any loudspeaker.
photos and info courtesy of BonaWatt
