The new Gold Note DSD Streamer with integrated DSD D/A converter is FULL CAPABLE DSD DIGITAL PLAYER, STREAMER, NET PLAYER, SERVER and D/A CONVERTER.
Performing DSD audio files from the net via LAN or W/LAN (WiFi) with integrated State-of-the-Art DSD USB D/A Converter with Coax and Optical input vertically integrated. The DS1000 is also able to play Internet web station working as player and streamer
ULTRA VERSATILE DESIGN
The DS1000 plays directly HDD and USB memories via two USB A ports avoiding the internal built in memories. Besides the DS1000 is a net player working W/LAN and LAN and also with NAS. The unit also integrates a D/A Converter playing all audio formats up to DSD 64/128. The DS1000 optionally features an integrated preamplifier and balanced analogue input.
GOLD NOTE TFT DISPLAY & SKC – Single Knob Control –
The Gold Note proprietary SKC and TFT display allow intuitive full unit control conveniently played by a single knob. The unit also is fully controlled WiFi: 802.11b/g
GOLD NOTE MODULAR DESIGN
Innovative unique modular design performing a variety of external units including two Class-A tube output stages, Atomic Master Clocks and High Power Supplies
TANK MECHANICAL STRUCTURE
DS-1000 features a great mechanical structure made of solid machined steel and thick aluminium panels guarantee low frequency resonance, feedback vibrational control and low magnetic inertial field.
PREAMP AND STEREO ANALOGUE INPUT STAGE (Optional)
Two options integrated preamplifier stage and balanced input to perform a full vertically integrated unit able to drive an audio system on its own
Dimensions: 430mm L | 135mm H | 375mm D
Weight: 15kg
Main features: DSD Streamer with integrated DSD D/A Converter
Frequency response: 5Hz-200kHz +/-0.3dB
THD – Total Harmonic Distortion: 0.001% max
Signal to noise ratio: -125dB
Dynamic response: 129dB
Output impedance: 50ohm
Phase response: linear phase, absolute phase inverted
Digital filter: proprietary Zero-Clock circuit enabling three different Master Clock
Volume control: switchable On/Off Digital partializer
Audio outputs: stereo RCA @ 2Volt and balanced XLR @ 4Volt
Line output level (fixed): 2V RMS RCA and 4V RMS XLR
Digital output: S/PDIF, 75ohm RCA 24bit
Audio inputs:
Digital input: one RCA S/PDIF coaxial and one TOS-optical asynchronous 24/192
USB: asynchronous DSD 64/128 and PCM up to 24/192 High Speed 2.0 port
USB: two USB-A front ports to feed USB flash memories, HDD FAT & NTFS
Analogue input (optional): Stereo balanced XLR
Connectivity:
LAN/WLAN WiFi: 802.11b/g via RJ45 10/100Mbps socket and Antenna
Infrared remote: RC5 proprietary code
Supported audio formats:
AIFF (.aif, .aiff, .aifc)
WAV (.wav) packed/unpacked
FLAC
WmA Windows media Audio 9
WAX Windows media audio metafiles
ASX Advanced Stream Redirector (.asx)
MPEG-4 Advanced Audio coding File, .aac, .m4a including Apple lossless, MP3
Supported media servers: All uPnP certified media servers
Power Mains supply: 100V to 245V, 50/60Hz, depending on market destination (not convertible)
Dual-Mono power supply
Power consumption: 30W
Upgrades:
TUBE-1012: Class-A 12 Tubes output stage with inductive tube power supply
PSU-1250: Dual-Mono 250Watt Super External Power supply
Preamp Stage: PGA electronically control single resistor dual-mono volume control preamp
Analogue input: Stereo balanced XLR
External AC filter: Gold Note Lucca AC distributor
Other: Gold Note Lucca power chord
Finishes:
Black or Silver brushed anodized front panel and case
Walnut or Aluminium black or silver anodized inserts
