The Luxman L-509Z has a completely redesigned ODNF1 amplifier negative feedback circuit, which was the heart of our L-509X flagship integrated amplifier released in 2017. Following the M-10X stereo power amplifier and the L-507Z integrated amplifier, this next-generation amplifier circuitry delivers extremely high-quality sound. LIFES2, our recently developed amplification feedback engine, is used in both the preamp and power amp stages for the first time and achieves a high-dimensional musicality and unprecedented scale as an integrated amplifier.
LECUA, our high-quality, electronically controlled attenuator mechanism that manages volume control, has evolved into LECUA-EX*3, combining a new rotary encoder with a weighted rotation mechanism to enable smoother and more precise volume control than ever before.
In terms of functionality, in order to further enhance the convenience of an audio amplifier required by modern music lovers, with a 7-segment LED level display making it easy to check the volume. A newly developed phono equalizer circuit compatible with MM and MC cartridges (2 step gain) provides more authentic enjoyment of analog record playback, which has been completely revived in competition with modern media. In order to actively control sound quality there is a 3-band tone control stage with additional dedicated midrange. We have added a new φ4.4mm headphone output terminal with independent left and right ground wiring and power supply interlocking for use with other equipment with trigger input/output and external control terminals, perfect specifications to satisfy a variety of audio playback tastes.
The L-509Z is a “one-body separate”, the ultimate expression of an integrated amplifier from LUXMAN, as we look forward to our 100th anniversary in 2025, still never compromising on quality. This product’s long-awaited debut as an integrated amplifier sees LUXMAN achieving the ideal balance of power, rich musicality and utility, covering multiple functions in one unit.
*1 ODNF stands for Only Distortion Negative Feedback *2 LIFES stands for Luxman Integrated Feedback Engine System *3 LECUA-EX stands for Luxman Electronically Controlled Ultimate Attenuator – Excellent eXperience
Features
Electronic circuitry and features
- Equipped with LUXMAN’s original amplification feedback engine LIFES 1.0 for both pre and power amp section.
- 3 stage Darlington equipped quadruple-paralleled push-pull configuration for a high output power rating of 240W x 2 (4Ω).
-Our LECUA electronically controlled attenuator system has evolved into LECUA-EX, combining a new rotary encoder with a weighted rotation mechanism to enable smoother, more precise volume control over 88 increments. - Highly stable power supply that combines a top quality El type 600VA power transformer and large capacity filter capacitors (8×10,000 μF ).
- Peel coat PCB are used for amplifier and audio circuit boards to eliminate any dielectric effects.
-A newly developed phono equalizer circuit compatible with MM and MC cartridges (2 step gain) for high grade analog record playback. - 3-band tone control with added MIDDLE that allows you to adjust the sound quality of the vocal band (BASS/MIDDLE/TREBLE).
- Bi-amp configuration with additional power amplifier and pre-power separation that enables coexistence with AV systems (SEPARATE function) and is equipped with two pre-outputs.
- A new mute button on the front panel (remote control can also be operated).
- Large, parallel configured speaker relays with low resistance, supporting excellent speaker drivability over direct-wired speaker terminals.
- Beeline construction that directs audio input signals via the optimum shortest route through to the speaker output and non-angled circuit board tracing realizes smooth current transmission in consideration of the current flow of delicate music signals.
- Internal wiring features unique OFC cabling that realizes natural signal transmission over non-plated copper core wire with spiral shielding. Design, Exterior
- Sensitive, needle-type analog meters with white LED illumination.
- Hairline top panel finish with fine cut ventilation holes, the same design as our M-10X.
- 7-segment LED for the volume level display with excellent visibility placed in the center of the large meters.
Mechanics, Accessories
- Equipped with RCA input terminals made from a copper alloy which delivers conductivity of copper and hardness of brass (LINE-1, 2).
- 18mm pitch RCA input/output terminals that support audiophile grade cables with large connectors (LINE-1 and LINE-2 are 20mm pitch).
- In-line (LR same characteristics) speaker terminal layout (A, B system) that are easy to connect to, even with thick cables, supporting Y terminators.
- In addition to the standard φ6.3mm terminal, a new φ4.4mm headphone terminal has been added, with left and right independent ground wiring that greatly improves L-R separation over the headphone outputs.
- Four large density gradient, cast iron feet that protect delicate music signals from vibration.
- New control input and output terminals link remote control signals between compatible devices and expand support for remote operation by other wireless devices looking toward the future.
- Equipped with a new trigger input and output terminal that enables power supply interlocking between compatible devices (3.5mm monaural jack, daisy chaining is also possible).
- High-end RA-17A aluminum remote control that can also operate compatible LUXMAN CD players made after 1996.
