Class: …………………………………………………………………AB
Nominal power output : 600W RMS under an 4-ohm load, 300W RMS under an 8-ohm load (compatible with a 1-ohm load)
Maximum output current : …………………..+ / – 75 amps
Maximum power pulse : ……………………………….4500W
DHT + N (A-Weighting) : …………….0.002 % (1KHz – 1W)
IMD (60Hz – 7KHz ; 4:1 ; 1W) : ……………………….0.004%
Bandwidth (1W) : ………………DC (0Hz) – 475 KHz (-3dB), DC (0Hz) – 190 KHz (-0.1dB)
Bandwidht (300W): …………….DC (0Hz) – 43 KHz (-0.1dB)
Damping factor : …………………> 480 under an 8-ohm load
Noise-to-signal ratio (A-Weighting) : ……………> 116dB
Voltage gain : ………………………………………………….32 dB
Sensitivity : ……………………………………………….1.4V RMS
Available inputs : ……………………………………….2 versions
Speaker outputs : ……WBT-0702.01 terminals with gold plating
Dimensions : ………………………………400 x 400 x 245 mm
Weight (For a standard amplifier) : ………………..47.5 Kg
