NEW CORE POWER TECHNOLOGIES USBE PERFECT

“Meet Core Power Technologies USBe Perfect. The USBe Perfect is designed to minimize signal degradation effects such as crosstalk and inter-symbol interference (ISI) that limits the interconnect distance between two devices. The following plots show the input and output of typical implementation based on USBe Perfect with a USB 3.0 Type A connector and a Std. USB3.0 3m long cable. Note the greatly improved Eye Mask indicating a more complete signal transmission and lower bit error rate on the right photo.”

Highlights

o Power Regeneration BUILT IN
o Integrates seamlessly for both USB 2.0 and USB 3.0 Protocols
o Vastly lowers Jitter
o The USBe Perfect is designed to minimize signal degradation effects such as crosstalk and inter-symbol interference (ISI) that limits the interconnect distance between two devices.
 o The input stage of each channel offers selectable equalization (optimization) settings that can be programmed to match loss in the channel. We have optimized this for USB Cables of 1 to 3 meters.
o The differential outputs provide selectable de-emphasis (again programmed for 1 to 3 meters) to compensate for the increased error rates & distortion that USB 3.0 signals experience.
o The level of de-emphasis depends on the length of interconnect and its characteristics. We can support 1 to 3-meter lengths easily.
On Sale Now With First Deliveries before Mid December
